Hot-print machine for license plates

Hot print machines, available for applying the finishing touch to the final car license plate, by transferring a lasting ink onto the characters and borders, in a matter of seconds. More versatile than its competitors, our various designs will cope with any quality (reflective) film and plate dimension at various settings, if required.

Economical Hot-print machine for license plates

• Easy to use: fully automatic machine!
• State-of-the-art contact less infrared temperature measurement
• Can print plates with and without border
• Pressure adjustable in more than 10 steps

Benefits

• Hinged heating elements for easy rubber roll changeover
• JKG development, our combined knowledge and experience in one machine
• Safety built in, protective cover, internal guarding sensors
• Standby mode reduces power consumption and increases useful rubber roll life

Technical specifications

Type : HP-ABR08
Dimensions (lxdxh) : 640 x 340 x 360 mm
Weight : 40 kg
Mains supply : 220V - 240V 50 Hz (1 phase)
Power (max.) : 1,1 kW
Temperature setting range : 140 - 210° C
Standby mode : If on, after 2 min, 10 - 80° C temp. reduction
Printing speed : Aprox. 3 m/min. (2 plates in 25 seconds)
Print media : Silicone rubber drum (100 mm Ø, width 125 or 134 mm) - Other width available on request
Lifetime rubber drum : More then 6 months, depending on temperature and amount of use
Printing material : Standard HP-foil (Hot-Print / Heiß-Präge) exterior type
Foil dimension : 80 - 130mm (variable) x 305 (500) meter
